Resinated Lignite KOL-RESX

Property:It is a kind of drilling fluid filtration reducer composed by sulfonated phenol-formaldehyde resin and sulfonated lignite, and can be used together with sulfonated asphalt, sulfonated tannin etc.

We're here to help: Easy ways to get the answers you need.

PDF Download

SEND E-MAIL GET PRICE

Share with:

Property
It is a kind of drilling fluid filtration reducer composed by sulfonated phenol-formaldehyde resin and sulfonated lignite, and can be used together with sulfonated asphalt, sulfonated tannin etc. Being heat and salt resistant at the same time, it is one of the ideal products for high temperature and deep well mud systems.

Use
It is a kind of copolymer contains hydroxyl, carbonyl, methyl, sulfonic acid base, nitriles and some other functional groups, and is made by grafting copolymerization and sulfonation. The main function is to reduce filtration loss, but it can also reduce viscosity at the same time.
It is heat-resistant because it draws sulfonic group into benzene ring unit, and the benzene ring is linked with carbon atoms. Owing to the introducing of sodium sulfonate SO3NA in benzene hydroxyl, it strengthens the hydration, which thus results in fine solubility. As a deep well mud treatment, Resinated Lignite owns the characteristics of reducing HTHP fluid loss, salt-resistant, calcium-resistant etc, and plays a great role in consolidating well wall, preventing collapsing and stucking. Recommended dosage: 1-3%
Storage & Package
25Kg net sealed in 4-in-1 compound paper bag with plastic lining during storage and transport see that the bag is intact.

Items

Indexes

Appearance

Free movement powder

Moisture content,%

≤18.0

PH

8.0-11.0

Sodium chloride polluted mud

AV, 180℃/16h After aging mpa·s

≤40.0

API,180℃/16h After aging ml/30min

≤15.0

150℃/3.5Mpa HTHP Filtration loss ml/30min

≤35.0

Fresh water mud

AV, 180℃/16h After aging mpa·s

≤15.0

API, 180℃/16h After aging ml/30min

≤10.0

150℃/3.5Mpa HTHP Filtration loss ml/30min

≤30.0
